25220
Viega Holding GmbH & Co. KG (Viega LLC) 25220 MegaPress® Elbow Fitting
1-1/2" x 1-1/2" MegaPressxMegaPress Schedule 5 to 40 200PSI Zinc Nickel Coated Carbon Steel Straight 90D Elbow with EPDM Sealing Element
Elbow Fitting; Type Straight; Angle 90 Degree; Size A 1-1/2 Inch; Size B 1-1/2 Inch; Schedule 5 to 40; End Connection MegaPress x MegaPress; Material Carbon Steel; Material Specification ASTM F3226; Finish Zinc Nickel Coated; Pressure Rating 200 PSI; Temperature Rating 0 to 250 Deg F; Application Chilled Water, Compressed Air, Hydronic Heating, Fire Sprinkler, Low Pressure Steam, Industrial Gas, Vacuum; Applicable Standard ANSI/CAN/UL 213, ASME B31/B31.1/B31.3/B31.9, CRN 23019.5 A/B/C, IAPMO, ICC LC1002, NFPA 13/13D/13R, FM; Includes EPDM Sealing Element, 420 Stainless Steel Grip Ring and 304 Stainless Steel Separator Ring
| Angle | : | 90 Degree |
| Applicable Standard | : | ANSI/CAN/UL 213, ASME B31/B31.1/B31.3/B31.9, CRN 23019.5 A/B/C, IAPMO, ICC LC1002, NFPA 13/13D/13R, FM |
| Application | : | Chilled Water, Compressed Air, Hydronic Heating, Fire Sprinkler, Low Pressure Steam, Industrial Gas, Vacuum |
| End Connection | : | MegaPress x MegaPress |
| Finish | : | Zinc Nickel Coated |
| Material Specification | : | ASTM F3226 |
| Material | : | Carbon Steel |
| Pressure Rating | : | 200 PSI |
| Product Name | : | Elbow Fitting |
| Schedule | : | 5 to 40 |
| Size A | : | 1-1/2 Inch |
| Size B | : | 1-1/2 Inch |
| Temperature Rating | : | 0 to 250 Deg F |
| Type | : | Straight |
- 1-1/2" x 1-1/2" MegaPressxMegaPress Schedule 5 to 40 200PSI Zinc Nickel Coated Carbon Steel Straight 90D Elbow with EPDM Sealing Element
| Package Quantity | : | 1 |
