440116.02.005

10-3 w/ Grd 0.21" x 0.91" Dia 500' L 600V 10AWG 3Conductor Yellow PVC Insulated Bare Copper Conductor THW Flat Parallel Submersible Pump Cable

Manufacturer Name: Kalas Manufacturing, Inc.
VAMAC PN: 107213
  • Min. Order Qty: 500
  • Qty. Interval: 500
  • Submersible Pump Cable; Type THW, Flat Parallel; Voltage Rating 600 Volt; Number of Conductors 3; Ground Type Yes; Conductor Size 10 AWG; Stranding 7/0.0385 Inch Strands; Conductor Material Bare Copper; Insulation Material PVC; Outer Diameter 0.21 Inch x 0.91 Inch; Color Code Yellow; Length 500 Foot; Temperature Rating -40 to 75 Deg C; Weight 195 Pound/1000 Foot; Approval UL 83, ISO 9001/14001; RoHS Compliant; Insulation Thickness 0.045 Inch

    Approval      :      UL 83, ISO 9001/14001
    Color Code      :      Yellow
    Conductor Material      :      Bare Copper
    Conductor Size      :      10 AWG
    Ground Type      :      Yes
    Insulation Material      :      PVC
    Length      :      500 Foot
    Number of Conductors      :      3
    Outer Diameter      :      0.21 Inch x 0.91 Inch
    Stranding      :      7/0.0385 Inch Strands
    Temperature Rating      :      -40 to 75 Deg C
    Type      :      THW, Flat Parallel
    Voltage Rating      :      600 Volt
    Weight      :      195 Pound/1000 Foot
  • ROHS Compliant
  • Made in USA
  • Multi-Conductor Submersible Cable
  • Resistant to Acid, Abrasion, Alkalis, Flame, Gas and Oil
  • Water and Sunlight Resistant
  • Cable is Sequentially Marked
  • Used for Wiring within the Casing of Deep Well Submersible Water Pumps
  • Package Weight      :      0.1264
    Package Weight Uom      :      Pound
    Package Quantity      :      1000
    Pack Desc      :      Foot
